Rotary Screening Bucket ZM1225
Rotary Screening Bucket ZM1225
WEIGHT: 150 KG
EXCAVATOR WEIGHT: 1.2 - 2.5 ton
ROTARY SCREEN DIAMETER: 500 mm
BUCKET WIDTH: 580 mm
Advanced rotary screening bucket with end-drum discharge mechanism designed for mini excavators in the 1.2-2.5 ton class. Compatible with ZA16A and ZA20A models, featuring dual mounting configurations to match respective pin specifications (25mm/30mm diameter). Compact dimensions: 1062mm length x 590mm width x 758mm height, weighing 155kg with Ø500mm screening drum. The rotating drum continuously agitates materials while automatically clearing particles from screen perforations, preventing clogging during operation. Standard 25mm mesh dimension with alternative mesh sizes available (optional). Integrated hydraulic controls with optional pressure and flow control valve for enhanced operation control. Perfect for soil separation, debris screening, and construction material sorting. Enhances operational flexibility and job site productivity by transforming your excavator into specialized screening equipment. Professional construction with 12-month warranty included
Starting at
106 000 Kč
128 260 Kč VAT included
🛡️
Extend your warranty — 2 years for only + 7 500 Kč
FACTORY OPTIONS
 |
Custom mesh size | + 3 200 Kč |
DETAILED SPECIFICATION
| System Pressure (MPa) | 10-12 |
| Rated flux (L/min) | 18-20 |
| Excavator Weight (ton) | 1.2 - 2.5 |
| Rotary Screen diameter (mm) | 500 |
| Rotary Speed (r/m) | 30-35 |
| Bucket Width (mm) | 580 |
| Length (mm) | 1062 |
| Height (mm) | 738 |
 |
2 years | + 7 500 Kč |
